| Analogue Inputs |
2x RCA Stereo (A1, A2), 1x Balanced XLR (A3) |
2x RCA Stereo (A1, A2), 1x Balanced XLR (A3) |
| Digital Inputs |
2x Coax (D1, D2) 2x Optical (D3, D4) Bluetooth Audio |
2x Coax (D1, D2) 2x Optical (D3, D4) Bluetooth Audio BluOS HDMI eARC |
| Analogue Outputs |
1x Balanced XLR (Pre1), 1x RCA Stereo (Pre2), 1x RCA Stereo (Pre3) |
1x Balanced XLR (Pre1), 1x RCA Stereo (Pre2), 1x RCA Stereo (Pre3) |
| Amplifier Output |
1x Pair of Speaker binding posts (L&R) |
1x Pair of Speaker binding posts (L&R) |
| Other Inputs/Outputs |
Wi-Fi 4, BLE, 12V Trigger, Wired IR |
Gigabit Ethernet RJ45, Wi-Fi 5, Wi-Fi 4, BLE, 12V Trigger, Wired IR |
| Power |
IEC C14, Fused 6.2AT |
IEC C14, Fused 6.2AT |
| User Interface |
Dynamic Control Dial (with haptic feedback), Black 15-button IR remote |
Same |
| Power Amplifier Technology |
Dual Mono Euphoria Amplifier, Class AB |
Dual Mono Euphoria Amplifier, Class AB |
| Output Power (8Ω) |
105W |
105W |
| Output Power (4Ω) |
200W |
200W |
| THD+N (1W @ 1kHz) |
<0.007% |
<0.007% |
| Gain |
29dB |
29dB |
| S/N Ratio (1W/8R) |
>85dB |
>85dB |
| Gain Matching |
<0.5dB |
<0.5dB |
| Frequency Linearity |
±0.25dB (20Hz - 20kHz) |
±0.25dB (20Hz - 20kHz) |
| Power Supply |
600VA / 36,400uF per rail |
600VA / 36,400uF per rail |
| Phono Inputs |
MM |
MM |
| Phono Gain |
53dB |
53dB |
| Phono Gain Adjustment |
Low (-6dB), Mid (0dB), High (+6dB) |
Low (-6dB), Mid (0dB), High (+6dB) |
| Input Impedance MM |
47k ohms / 100pF |
47k ohms / 100pF |
| RIAA Response Accuracy |
±0.3dB (20Hz - 20kHz) |
±0.3dB (20Hz - 20kHz) |
| DAC Technology |
Rapture DAC, Dual Mono Balanced |
Rapture DAC, Dual Mono Balanced |
| DAC Format Support |
PCM |
PCM |
| Sampling Rate |
up to 24bit / 192kHz |
up to 24bit / 192kHz |
| Preamp (Amp, Pre1, Pre2) |
Hybrid Digital Analogue volume control |
Same |
| Preamp (Pre3) |
Digital volume control |
Same |
| Volume Control Matching |
<0.25dB |
<0.25dB |
| THD+N (3.9Vrms, A-weighted) |
<0.0008% (Amp, Pre1, Pre2)<0.003% (Pre3) |
Same |
| S/N Ratio (3.9Vrms, A-weighted) |
>108dB |
Same |
| Max Output Level |
3.9Vrms |
3.9Vrms |
| Supported Features |
Pre-Output, Line Level Output (Fixed Level), Sub-Woofer Output (Low-Pass Filtered), Intelligent DSP |
Same |
| Bluetooth Protocol |
A2DP Audio Profile |
A2DP Audio Profile |
| Bluetooth Codecs |
SBC, aptX & AAC |
SBC, aptX & AAC |
| Bluetooth Range |
>15m |
>15m |
| HDMI ARC/eARC |
No |
Yes (2.0) |
| Maximum Input Level |
6.7Vrms |
6.7Vrms |
| Music Sense/AV Mode |
A2 Input |
A2 Input |
| BluOS |
No |
Yes |
| Hi-Res Audio |
- |
MQA, FLAC, WAV, AIFF (converted DSD via desktop app) |
| Sampling Rate / Bit Depth |
- |
up to 192kHz, 16-24bit |
| Network Connectivity |
- |
Gigabit Ethernet RJ45, Wi-Fi 5 |
| Network File Storage Protocol |
- |
SMB |
| USB |
- |
1x Type-A (FAT32 or NTFS) |
| Supported OS |
- |
Windows XP+, macOS |
| Mobile App |
- |
BluOS Controller app (iOS, Android, Windows, macOS) |
| Streaming Services |
- |
20+ natively integrated (Apple Airplay, Spotify Connect, Tidal Connect) |
| ROON Ready |
- |
TBC |
| Control Integrations |
- |
Crestron, Control4, RTI, URC, Lutron, NICE, GIRA, BluOS API |
| Maestrounite Supported |
Yes |
Yes |
| Wired IR Input |
5-14V, Mono 3.5mm jack plug, any polarity |
Same |
| 12V Trigger Input |
5-14V, 3.5mm jack dual polarity (On/Standby) |
Same |
| 12V Trigger Pass-through |
3.5mm jack, Pass-through from input only |
Same |
| Nominal Mains Voltage |
Auto-selecting 100-120VAC & 220-240VAC |
Same |
| Power Consumption |
Max 610VA, Standby 0.5W, Network Standby 2W (fast boot) |
Same |
| Finishes |
Silver, Black |
Silver, Black |
| Construction |
Extruded and machined aluminium front & top cover with extruded aluminium heatsinks |
Same |
| Dimensions (H x W x D) |
93 x 432 x 378mm (3 11/16 x 17 x 14 7/8”) |
Same |
| Weight |
15.2 kg (33 lb 8 oz) |
15.5 kg (34 lb 3 oz) |
| Sold As |
Single |
Single |
